COUNTERSUNK HEAD SOLID RIVETS DIN 661 COUNTERSUNK HEAD SOLID RIVETS DIN 661 COUNTERSUNK HEAD SOLID RIVETS DIN 661 COUNTERSUNK HEAD SOLID RIVETS DIN 661 COUNTERSUNK HEAD SOLID RIVETS DIN 661 COUNTERSUNK HEAD SOLID RIVETS DIN 661

COUNTERSUNK HEAD SOLID RIVETS DIN 661

NumberTypePart No.Specification
1COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102062 X 6 COUNTERSUNK HEAD SOLID RIVET (GRIP=4.0) DIN 661 A2 STAINLESS STEEL
2COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102082 X 8 COUNTERSUNK HEAD SOLID RIVET (GRIP=6.0) DIN 661 A2 STAINLESS STEEL
3COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102102 X 10 COUNTERSUNK HEAD SOLID RIVET (GRIP=7.5) DIN 661 A2 STAINLESS STEEL
4COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102122 X 12 COUNTERSUNK HEAD SOLID RIVET (GRIP=9.5) DIN 661 A2 STAINLESS STEEL
5COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102142 X 14 COUNTERSUNK HEAD SOLID RIVET (GRIP=10.5) DIN 661 A2 STAINLESS STEEL
6COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102162 X 16 COUNTERSUNK HEAD SOLID RIVET (GRIP=12) DIN 661 A2 STAINLESS STEEL
7COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102182 X 18 COUNTERSUNK HEAD SOLID RIVET (GRIP=14) DIN 661 A2 STAINLESS STEEL
8COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102202 X 20 COUNTERSUNK HEAD SOLID RIVET (GRIP=15) DIN 661 A2 STAINLESS STEEL
9COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102222 X 22 COUNTERSUNK HEAD SOLID RIVET (GRIP=17) DIN 661 A2 STAINLESS STEEL
10COUNTERSUNK HEAD SOLID RIVETS DIN 661A66102252 X 25 COUNTERSUNK HEAD SOLID RIVET (GRIP=20) DIN 661 A2 STAINLESS STEEL
11COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103063 X 6 COUNTERSUNK HEAD SOLID RIVET (GRIP=4.0) DIN 661 A2 STAINLESS STEEL
12COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103083 X 8 COUNTERSUNK HEAD SOLID RIVET (GRIP=6.0) DIN 661 A2 STAINLESS STEEL
13COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103103 X 10 COUNTERSUNK HEAD SOLID RIVET (GRIP=7.5) DIN 661 A2 STAINLESS STEEL
14COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103123 X 12 COUNTERSUNK HEAD SOLID RIVET (GRIP=9.5) DIN 661 A2 STAINLESS STEEL
15COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103143 X 14 COUNTERSUNK HEAD SOLID RIVET (GRIP=10.5) DIN 661 A2 STAINLESS STEEL
16COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103163 X 16 COUNTERSUNK HEAD SOLID RIVET (GRIP=12) DIN 661 A2 STAINLESS STEEL
17COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103183 X 18 COUNTERSUNK HEAD SOLID RIVET (GRIP=14) DIN 661 A2 STAINLESS STEEL
18COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103203 X 20 COUNTERSUNK HEAD SOLID RIVET (GRIP=15) DIN 661 A2 STAINLESS STEEL
19COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103223 X 22 COUNTERSUNK HEAD SOLID RIVET (GRIP=17) DIN 661 A2 STAINLESS STEEL
20COUNTERSUNK HEAD SOLID RIVETS DIN 661A66103253 X 25 COUNTERSUNK HEAD SOLID RIVET (GRIP=20) DIN 661 A2 STAINLESS STEEL
21COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104064 X 6 COUNTERSUNK HEAD SOLID RIVET (GRIP=3.5) DIN 661 A2 STAINLESS STEEL
22COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104084 X 8 COUNTERSUNK HEAD SOLID RIVET (GRIP=5.5) DIN 661 A2 STAINLESS STEEL
23COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104104 X 10 COUNTERSUNK HEAD SOLID RIVET (GRIP=7.0) DIN 661 A2 STAINLESS STEEL
24COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104124 X 12 COUNTERSUNK HEAD SOLID RIVET (GRIP=9.0) DIN 661 A2 STAINLESS STEEL
25COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104144 X 14 COUNTERSUNK HEAD SOLID RIVET (GRIP=10.5) DIN 661 A2 STAINLESS STEEL
26COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104164 X 16 COUNTERSUNK HEAD SOLID RIVET (GRIP=12) DIN 661 A2 STAINLESS STEEL
27COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104184 X 18 COUNTERSUNK HEAD SOLID RIVET (GRIP=14) DIN 661 A2 STAINLESS STEEL
28COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104204 X 20 COUNTERSUNK HEAD SOLID RIVET (GRIP=15) DIN 661 A2 STAINLESS STEEL
29COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104224 X 22 COUNTERSUNK HEAD SOLID RIVET (GRIP=17) DIN 661 A2 STAINLESS STEEL
30COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104254 X 25 COUNTERSUNK HEAD SOLID RIVET (GRIP=20) DIN 661 A2 STAINLESS STEEL
31COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104284 X 28 COUNTERSUNK HEAD SOLID RIVET (GRIP=22) DIN 661 A2 STAINLESS STEEL
32COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104304 X 30 COUNTERSUNK HEAD SOLID RIVET (GRIP=24) DIN 661 A2 STAINLESS STEEL
33COUNTERSUNK HEAD SOLID RIVETS DIN 661A66104354 X 35 COUNTERSUNK HEAD SOLID RIVET (GRIP=27) DIN 661 A2 STAINLESS STEEL
34COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105085 X 8 COUNTERSUNK HEAD SOLID RIVET (GRIP=5.0) DIN 661 A2 STAINLESS STEEL
35COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105105 X 10 COUNTERSUNK HEAD SOLID RIVET (GRIP=7.0) DIN 661 A2 STAINLESS STEEL
36COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105125 X 12 COUNTERSUNK HEAD SOLID RIVET (GRIP=9.0) DIN 661 A2 STAINLESS STEEL
37COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105145 X 14 COUNTERSUNK HEAD SOLID RIVET (GRIP=10) DIN 661 A2 STAINLESS STEEL
38COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105165 X 16 COUNTERSUNK HEAD SOLID RIVET (GRIP=12) DIN 661 A2 STAINLESS STEEL
39COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105185 X 18 COUNTERSUNK HEAD SOLID RIVET (GRIP=13) DIN 661 A2 STAINLESS STEEL
40COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105205 X 20 COUNTERSUNK HEAD SOLID RIVET (GRIP=15) DIN 661 A2 STAINLESS STEEL
41COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105225 X 22 COUNTERSUNK HEAD SOLID RIVET (GRIP=17) DIN 661 A2 STAINLESS STEEL
42COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105255 X 25 COUNTERSUNK HEAD SOLID RIVET (GRIP=20) DIN 661 A2 STAINLESS STEEL
43COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105285 X 28 COUNTERSUNK HEAD SOLID RIVET (GRIP=22) DIN 661 A2 STAINLESS STEEL
44COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105305 X 30 COUNTERSUNK HEAD SOLID RIVET (GRIP=24) DIN 661 A2 STAINLESS STEEL
45COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105355 X 35 COUNTERSUNK HEAD SOLID RIVET (GRIP=27) DIN 661 A2 STAINLESS STEEL
46COUNTERSUNK HEAD SOLID RIVETS DIN 661A66105405 X 40 COUNTERSUNK HEAD SOLID RIVET (GRIP=32) DIN 661 A2 STAINLESS STEEL
47COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106106 X 10 COUNTERSUNK HEAD SOLID RIVET (GRIP=6.5) DIN 661 A2 STAINLESS STEEL
48COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106126 X 12 COUNTERSUNK HEAD SOLID RIVET (GRIP=8.5) DIN 661 A2 STAINLESS STEEL
49COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106146 X 14 COUNTERSUNK HEAD SOLID RIVET (GRIP=10) DIN 661 A2 STAINLESS STEEL
50COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106166 X 16 COUNTERSUNK HEAD SOLID RIVET (GRIP=11.5) DIN 661 A2 STAINLESS STEEL
51COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106186 X 18 COUNTERSUNK HEAD SOLID RIVET (GRIP=13) DIN 661 A2 STAINLESS STEEL
52COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106206 X 20 COUNTERSUNK HEAD SOLID RIVET (GRIP=15) DIN 661 A2 STAINLESS STEEL
53COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106226 X 22 COUNTERSUNK HEAD SOLID RIVET (GRIP=17) DIN 661 A2 STAINLESS STEEL
54COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106256 X 25 COUNTERSUNK HEAD SOLID RIVET (GRIP=20) DIN 661 A2 STAINLESS STEEL
55COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106286 X 28 COUNTERSUNK HEAD SOLID RIVET (GRIP=22) DIN 661 A2 STAINLESS STEEL
56COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106306 X 30 COUNTERSUNK HEAD SOLID RIVET (GRIP=24) DIN 661 A2 STAINLESS STEEL
57COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106356 X 35 COUNTERSUNK HEAD SOLID RIVET (GRIP=27) DIN 661 A2 STAINLESS STEEL
58COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106406 X 40 COUNTERSUNK HEAD SOLID RIVET (GRIP=32) DIN 661 A2 STAINLESS STEEL
59COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106456 X 45 COUNTERSUNK HEAD SOLID RIVET (GRIP=35) DIN 661 A2 STAINLESS STEEL
60COUNTERSUNK HEAD SOLID RIVETS DIN 661A66106506 X 50 COUNTERSUNK HEAD SOLID RIVET (GRIP=40) DIN 661 A2 STAINLESS STEEL


Parameter
Diameter (d1)d2 (nom)d3 (min)e (max)k (nom)
23.51.871.01
35.22.871.51.4
473.872.02
58.84.822.52.5
610.55.823.03
